Description
Features:
The PD decoy supports PD3.0/2.0, BC1.2 and other boost and fast charging protocols, supports up to 10w power, and provides over-temperature, over-voltage protection and other functions.
The voltage can be adjusted by the dial switch, and the maximum output voltage is 20V.
Support fast charging protocols such as PD3.0/2.0 and BC1.2
Supports USB Type-C PD, forward and reverse insertion detection and automatic switching
Support 4V to 22V input voltage
Product parameters:
Input voltage: support 4V to 22V
Output voltage: up to 20V
Interface: support USB Type-C PD
Power: up to 100W
Product size: 11 * 25.7mm
Instructions:
CFG1 corresponding dial switch 1
CFG2 corresponding dial switch 2
CFG3 corresponds to dial switch 3
Dial down to 1, and dial up to 0.
Toggle the switch to request the corresponding voltage according to the charger protocol
